GL180TFT10B is a color-round active matrix Thin film transistor(TFT)liquid crystal display(LCD) with a capacitive touchscreen that uses amorphous silicon TFT as a switching device. This TFT LCD has a 1.8-inch diagonally measured active display area with (360 horizontal by 360 vertical pixels)resolution.
| Item No. | GL180TFT10B |
|---|---|
| MOQ | 2pcs |
| Samples | In Stock |
| Lead Time | 7 Working Days |
| Payment Term | Paypal, T/T |
| Status | Mass Production |
| Availability | 5 Years Stable Supply |
| Customization | Support |
GL180TFT10B is a color-round active matrix Thin film transistor(TFT)liquid crystal display(LCD) with a capacitive touchscreen that uses amorphous silicon TFT as a switching device. This TFT LCD has a 1.8-inch diagonally measured active display area with (360 horizontal by 360 vertical pixels)resolution.
| Features | Specification | Unit |
|---|---|---|
| Display Size(Diagonal) | 1.8 | inch |
| Resolution | 360*360 | |
| LCD Type | a-Si TFT LCD | |
| View Direction | IPS | |
| Outline Dimension | 58.68(H)*58.68(V)*3.11(T) | mm |
| Active Area | 45.684(H)* 45.684(V) | mm |
| Display Colors | 262K | |
| Display Mode | Normally Black. Transmissive TFT | |
| LCM Interface | MIPI 4Lane | |
| Driver IC | ST77916 | |
| Brightness | 400 | cd/m2 |
| Pin Number | 20Pin 0.5mm | |
| Operation Temperature | -20 to 70 | |
| Storage Temperature | -30 to 80 |
7-Day Delivery LCD Display Factory, Customization Solution is Available.
